Unit 1

Template Layout Area

Template Area of 750 m2

To comply with the stringent quality standards set by the Research Designs and Standards Organisation (RDSO) for Indian Railways projects, MIPL operates a dedicated RDSO Template Layout Area spanning 750 SQM (15 m × 50 m).

Dimensional Accuracy: Eliminates field-level alignment issues through pre-fabrication lofting and template cross-verification.

RDSO Compliant: Meets mandatory RDSO infrastructure guidelines for vendor approval and structural bridge girder manufacturing.

High Throughput: Supports MIPL’s production capacity, allowing simultaneous template marking and trial fitting for high-volume orders.

Space can be Expanded lengthwise to more than double if needed as entire floor is levelled and concreted and can be adapted to Templating usage if needed.

Highlights

Full-Scale 1:1 Camber & Nominal Floor Lofting :
The clear 50-meter length accommodates 1:1 scale marking for standard RDSO open-web and composite plate spans up to 48m in a single layout setup. This satisfies the length and flatness criteria required for precise floor lofting

Complex Span Handling: The 50-meter clear length easily accommodates long-span components, including RDSO-approved Open Web Girders, Road Over Bridges (ROBs), Foot Over Bridges (FOBs), and Bowstring Girders.

Quality Assurance & Jig Verification: This facility serves as a primary control station for preparing master templates, verifying hole pitch alignment, checking node geometry, and setting up assembly jigs under strict Quality Assurance Plan (QAP) compliance.

Seamless Process Integration: Located within our state-of-the-art facility in Hathkhoj, Bhilai, the template area links directly into our automated fabrication, CNC cutting, blasting, and trial assembly bays, ensuring streamlined workflow and zero-error tolerances.
Template Area is under EOT Crane capacity of 50/20 MT.

Compliance

All production drilling is executed using rigid jigs derived from calibrated master templates.

Working jigs are controlled to RDSO-mandated tolerances Dedicated space needed to fabricate and verify Master Jigs against nominal drawings. (+0.0 mm to -0.13 mm for plate alignment and -0.0 mm to +0.1 mm for bush bore tolerances), preventing oversizing during mass production.

Stage-wise inspection clearances by approved agencies (RITES / Zonal Railway FIU) before cutting or drilling begins.

Inspecting engineers can visually inspect 1:1 scribed lines, gusset geometries, and hole pitch centers before releasing materials to CNC cutting and tack-assembly bays.

Laying out members on the level floor ensures that edge distances, cutting allowances (3 mm for plates, 6 mm for plates) and diagonal squareness meet exact design values.

The template area provides pre-checked component dimensions that ensure distortion-free fit-ups under approved WPSS specifications.

Fabrication Shop

Cutting

1. CNC/Multi-head gas cut machine, Model: GS/Z – 4000

2. MIURA VK-3500 C/W

Cutting & Drilling

1. ASIA MACHINE GROUP, FSC6500D X 32M, Taiwan
CNC Plasma/Gas Cutting/Drilling/ Marking machine & Table top support.
2. MIURA Machine VK6500 C/D-40
3. MIURA Machine VK6500 C/D-50
3. FICEP 1103DEB, Italy. - High Speed Drilling & Sawing Line with Hard Marking
4. PEDDINGHAUS FDB 600 HS, Germany - Plate Processing Machine Drilling & Burning Line.
5. PEDDINGHAUS TDK 1000/9 + LC 1250, Germany - Structural Drill Line With Horizontal Circular Saw

Welding

1. Double Cantilever Submerged Arc Welding Machine, Model: MZGT-2000
2. COLUMN BOOM 6M X 6M WITH 1200 AMPS SAW WELDING M/C MOGRA
3. Portable SAW welding machines 1200 AMP LINCOIN KAIYUAN - MOGRA
4. Multiple welding machines (ARC Welding) Panasonic, (D & H)
5. Multiple CO2 welding machines (KEMPPI- D&H)
6. KOCO ELOTOP 3020 Stud welding machines (Welding Upto 25 Mm Dia With 2 Nos Welding Torch)

Straightening

1. H Beam Flange Hydraulic Pressure Straightening Machine, Model: YJ-80

Max Web Height 350mm
Thickness of web 6-60mm,
Width of flange 200-1100mm,
Thickness of flange 6-80mm

End Milling

1. Face Milling Machine, Model: DX 1224
Milling Height / Width - 1200mm / 2400mm
Plane / Vertical Feeding Depth
200 - 650 m/ min
Knife Tray Specifications - 12 teeth

2. End Face Milling Machines - 2 nos.

- Max Job height 1200mm,
- Max Job Width 2400mm +4000+4000

Blasting Shop

Shot Blast machine 1

Trolley Type Shot Blasting
- 10 Nos. blasting nozzle,
- Max job height 2400mm,
- Max job width 1400mm.

Shot Blast Machine 2

Roller Type Shot Blasting
- 4 Nos. blasting nozzle,
- Max job height 600 mm,
- Max job width 600 mm.

Shot Blast Booths

2 nos. Shot Blast Booths
each 25m x 8m x 10m size
Serviced by 50 MT trolley
Full floor recovery system & cartridge dust collectors.

Shot / Grit Booth

1 no. Shot/Grit Blast Booth
Size 26 m x 16m x 8m.
Serviced by 50 MT trolley.

Fabrication of Open Web Girder, Composite Girder and Other Steel Plate Girder Part A
(Item ID 3100425 & Sub Item ID 3100425002).

Registration ID. - 56508
Annual Production Capacity - 30,000 MT.
Last Quality Audit done on - 07.11.2025
NEXT Quality Audit Due on - 24.10.2030

UDYAM registration number : UDYAM-CG-05-0000452
Udyog Aadhaar Memorandum Number : CG05B0002864

Type of Enterprise : MANUFACTURING

Classification Year : 2025-26
Enterprise Type : MEDIUM
Classification Date : 01/04/2025

Major Activity : MANUFACTURING
Social Category of Entrepreneur : GENERAL

Date of incorporation : 07/06/2005
Date of commencement of production / business : 15/02/2010

SCAN QR CODE FOR MORE DETAILS

Factory License No : 15049/15049/G-FAB/DRG/2m(i)

Please scan QR code for verification on https://shramevjayate.cg.gov.in/

1. Certifying Body : Bureau of Indian Standards
2. Date of Certification : 13 Nov 2025, License No : QM/L - 5004936.
3. Last Date of Surveillance Audit : 21&22 July 2026
4. Last Date of Internal Audit : 12 June 2026
Compliance details : All NCR resolved.

ADDRESS

SHED 1

SHED 2

OPEN GANTRY AREA

Template Layout Area

Template Area of 750 m2

Highlights

Compliance

Fabrication Shop

Cutting

Cutting & Drilling

Welding

Straightening

End Milling

Blasting Shop

Shot Blast machine 1

Shot Blast Machine 2

Shot Blast Booths

Shot / Grit Booth

Metalizing and Painting shop

Metalizing

Paint Booths

Assembly Area

Assembly Area

RM Stacking area

Stacking Area

Other Facilities

Office Block

Roof Top Solar

100 MT Weigh Bridge

Organisation Chart

DETAILS OF TESTING FACILITIES

Physical / Chemical / Mechanical

In House :Hydraulic & Pneumatic, Pressure gauge : 5 to 250 KG/CM2Outsourced :Mechanical : UTM Chemical : Spectro/Wet process.

DPT

In House : DP Test: ASME SEC VIII Div-1, APP-8Outsourced :MPI Test : ASME SEC VIII Div-1, APP-6.

UT / PAUT / RT

Inhouse : UT Test : For Weld Joint ASME SEC VIII, Div-1, APP-12 UT Test : For Plate ASTM A 435 & A578 Level A,B,COutsourced :PAUT Test : ASME SEC VIII Div-1, APP-12.(weld)RT Test : ASME SEC VIII Div-1, APP-4.

POWER CAPACITY

01. 560 KVA from CSEB (Sanctioned Load) 950/1000 KVA Transformer MP. Transformer 02. Own Power Generation 320 KVA (DG Set – Cummins Make)-1 NO 03. 560 KWp Roof Top Solar Plant.

Miura Infrastructure Private Limited

In House :
Hydraulic & Pneumatic, Pressure gauge : 5 to 250 KG/CM2

Outsourced :
Mechanical : UTM
Chemical : Spectro/Wet process.

In House :
DP Test: ASME SEC VIII Div-1, APP-8

Outsourced :
MPI Test : ASME SEC VIII Div-1, APP-6.

Inhouse :
UT Test : For Weld Joint ASME SEC VIII, Div-1, APP-12
UT Test : For Plate ASTM A 435 & A578 Level A,B,C

Outsourced :
PAUT Test : ASME SEC VIII Div-1, APP-12.(weld)

RT Test : ASME SEC VIII Div-1, APP-4.

01. 560 KVA from CSEB (Sanctioned Load) 950/1000 KVA Transformer MP. Transformer
02. Own Power Generation 320 KVA (DG Set – Cummins Make)-1 NO
03. 560 KWp Roof Top Solar Plant.
